NUMERICAL OC/EF PROTECTION RELAY ADR141C/241C
ASHIDA Electronics Pvt. Ltd.
Ref: Manual / ADR141C / 241C
Issue: 04D
Date : 10.07.2014
Page 23/86
8.3 MENUS
8.3.1 Default Display
After Power ON or when the HW RESET and LED RESET/EDIT push button is pressed
simultaneously, the relay will display the following message.
8.3.2 Main Menu List
Primary current
General Settings
Relay setting
Cold Load
Relay/LED Config
Trip Test
Fault 1
Fault 2
Fault 3
Fault 4
Fault 5
Fault 6
Fault 7
Primary Current, General Settings, Relay setting, Cold Load,
Relay/LED Config, Trip Test, Fault 1, Fault 2, Fault 3, Fault
4, Fault 5, Fault 6, Fault 7, Fault 8, Events Log, Error Log,
Status, Date/Time, and Secondary Current these are the
Main Menus available in this relay.
Since the LCD Display consist only of 2 Lines, the main
menu list can be scrolled up or down by using the up arrow
key (+ / ) or the down arrow key ( - / ).
Ashida Digital
OC/EF Relay
This window will flash momentarily showing the following
Relay Name: OC/EF Relay
Then the control will go automatically to next window.
R = 0000 Y = 0000
B = 0000A
This is default window showing the actual Primary Load
Current as per “CT Pri” selection.
R = 0000 Y = 0000
B = 0000A
This is default window showing the actual Primary Load
Current as per “CT Primary” selection
Press the left arrow key () the relay will display Main menu
directly as follows.
ADR141C - Ver. 01.20
Unit ID : 0001
This window will flash momentarily showing the following
Relay Type : ADR141C Software Version : V01.20
Unit ID = 0001
Then the control will go automatically to default window
To Next Page
