8.3.6.2 To View – COLD LOAD Setting
Cold Load
Cold Load Setting
Press the right arrow key () the relay will display as follows.
CL Enable = Yes
CL Timer = 0.50
This window will show Cold Load setting done previously.
Press the right arrow key () the relay will display as follows.
IP> 250% t = X1.00
IP>> 1000%
This window will show Cold Load setting done previously.
Press the right arrow key () the relay will display as follows.
3Io> 250% t = X1.00
3Io>> 3000%
This window will show Cold Load setting done previously.
Press the right arrow key () the relay will display as follows.
IP> Enable = YES
IP>> Enable = YES
This window will show Cold Load setting done previously.
Press the right arrow key () the relay will display as follows.
3Io> Enable = NO
3Io>> Enable = NO
This window will show Cold Load setting done previously.
Press the right arrow key () the relay will display as follows.
IP> Normal Inv. 1
3Io> Normal Inv. 1
This window will show Cold Load setting done previously.
Press the right arrow key () the relay will display as follows.
IP>> Delay = 0.00
3Io>> Delay = 0.00
This window will show Cold Load setting done previously.
Press the right arrow key () the relay will display as follows.
IP> C6 Delay = 00.5
3Io> C6Delay = 01.0
This window will show Cold Load setting done previously.
Press the right arrow key () the relay will display the main
menu.
