8.3.3 Primary Current
8.3.3.1 To View – Primary Current
Pri. Current
Date/Time
Password protected window for setting “Date/Time’’
Press the down arrow key (- /) the relay will display as
follows.
Sec. Current
This menu is to view the actual load current in Secondary as
per the CT Secondary selection.
Press the down arrow key (- /) the relay will display as
follows.
Pri. Current
This menu is to view the actual load current in Primary as
per the CT Primary selection.
Press the right arrow key () the relay will display as
follows.
R = 0000 Y = 0000
B = 0000A
This window will show Primary load current of R, Y & B.
Press the right arrow key () the relay will display as
follows.
3Io = 0000A
This window will show Primary load current of 3Io.
Press the right arrow key () the relay will display main menu
Pri. Current
