NUMERICAL OC/EF PROTECTION RELAY ADR141C/241C
ASHIDA Electronics Pvt. Ltd.
Ref: Manual / ADR141C / 241C
Issue: 04D
Date : 10.07.2014
Page 50/86
Relay/ LED Config.
L2 Green A = 0000
L2 Green B = 0000
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
L2 Red A = 8000
L2 Red B = 01FF
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
L3 Green A = 0000
L3 Green B = 0000
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
L4 Green A = 0000
L4 Green B = 0000
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
L4 Red A = 8000
L4 Red B = 01FF
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display the
main menu.
L3 Red A = 8000
L3 Red B = 01FF
This window will show Relay config. setting done
previously.
Press the right arrow key () the relay will display as
follows.
