NUMERICAL OC/EF PROTECTION RELAY ADR141C/241C
ASHIDA Electronics Pvt. Ltd.
Ref: Manual / ADR141C / 241C
Issue: 04D
Date : 10.07.2014
Page 48/86
Relay/ LED Config.
Save Settings?
Mode for Save
To Save any changes.
Press the left arrow key () the relay will save the change
and the following message is display.
Note: If changes made are not to be saved press LED
Reset or leave key pad untouched for 100Sec.
OK
This window will flash for moment
The control will return to the main menu
L4 Red A = 0000
This window shows the Relay/LED configuration. That is L3
Red A.
Press the left arrow ke
y
(

)
the rela
y
will dis
p
la
y
as follows.
L4 Red B = 0400
This window shows the Relay/LED configuration. That is L3
Red B.
Press the left arrow key () the relay will display as follows.
