NUMERICAL OC/EF PROTECTION RELAY ADR141C/241C
ASHIDA Electronics Pvt. Ltd.
Ref: Manual / ADR141C / 241C
Issue: 04D
Date : 10.07.2014
Page 47/86
L2 Green B = 0000
This window shows the Relay/LED configuration. That is L2
Green B.
Press the left arrow ke
y
(

)
the rela
y
will dis
p
la
y
as follows.
L2 Red A = 0000
This window shows the Relay/LED configuration. That is L2
Red A.
Press the left arrow key () the relay will display as follows.
L2 Red B = 01FF
This window shows the Relay/LED configuration. That is L2
Red B.
Press the left arrow ke
y
(

)
the rela
y
will displa
y
as follows.
L3 Green A = 0000
This window shows the Relay/LED configuration. That is L3
Green A.
Press the left arrow key () the relay will display as follows.
L3 Green B = 0000
This window shows the Relay/LED configuration. That is L3
Green B.
Press the left arrow key () the relay will display as follows.
L3 Red A = 0000
This window shows the Relay/LED configuration. That is L3
Red A.
Press the left arrow key () the relay will display as follows.
L3 Red B = 0400
This window shows the Relay/LED configuration. That is L3
Red B.
Press the left arrow key () the relay will display as follows.
L4 Green A = 01FF
This window shows the Relay/LED configuration. That is L4
Green A.
Press the left arrow key () the relay will display as follows.
L4 Green B = 0000
This window shows the Relay/LED configuration. That is L4
Green B.
Press the left arrow key () the relay will display as follows.
