NUMERICAL OC/EF PROTECTION RELAY ADR141C/241C
ASHIDA Electronics Pvt. Ltd.
Ref: Manual / ADR141C / 241C
Issue: 04D
Date : 10.07.2014
Page 46/86
RL3 B = 0000
This window shows the Relay/LED configuration. That is
RL3 B
Press the left arrow key () the relay will display as follows.
RL4 A = 01FF
This window shows the Relay/LED configuration. That is
RL4 A
Press the left arrow key () the relay will display as follows.
RL4 B = 0000
This window shows the Relay/LED configuration. That is
RL4 B.
Press the left arrow key () the relay will display as follows.
L1 Green A = 4000
This window shows the Relay/LED configuration. That is L1
Green A.
Press the left arrow key () the relay will display as follows.
L1 Green B = 0000
This window shows the Relay/LED configuration. That is L1
Green B.
Press the left arrow key () the relay will display as follows.
L1 Red A = 8000
This window shows the Relay/LED configuration. That is L1
Red A
Press the left arrow key () the relay will display as follows.
L1 Red B = 0000
This window shows the Relay/LED configuration. That is L1
Red B
Press the left arrow key () the relay will display as follows.
L2 Green A = 0000
This window shows the Relay/LED configuration. That is L2
Green A
Press the left arrow key () the relay will display as follows.
