Fault 1
This menu is to view the latest Fault data stored by the relay.
That is Trip Flags, Instantaneous and Phase primary Current,
Trip Counter (TC), Fault Date & Time.
Press the down arrow key (- /) the relay will display as
follows.
Fault 2
This menu is to view the First latest Fault data stored by the
relay. That is Trip Flags, Instantaneous and Phase primary
Current, Trip Counter (TC), Fault Date & Time.
Press the down arrow key (- /) the relay will display as
follows.
Relay/LED Config
Password protected window for “Relay
/
LED Config.” for
Setting Password, Load fact Set, RL1 A, RL1 B, RL2 A, RL2
B, RL3 A, RL3 B, RL4 A, RL4 B, L1 Green A, L1 Green B, L1
Red A, L1 Red B, L2 Green A, L2 Green B, L2 Red A, L2 Red
B, L3 Green A, L3 Green B, L3 Red A, L3 Red B, L4 Green A,
L4 Green B, L4 Red A and L4 Red B.
Press the down arrow key ( - /) the relay will display as
follows.
Trip Test
This function is used for Tripping purpose that is by pressing
on Right Arrow key ().
Press the down arrow key (- /) the relay will display as
follows.
Fault 3
This menu is to view the second latest Fault data stored by
the relay. That is Trip Flags, Instantaneous and Phase
primary Current, Trip Counter (TC), Fault Date & Time.
Press the down arrow key (- /) the relay will display as
follows.
Fault 4
This menu is to view the third latest Fault data stored by the
relay. That is Trip Flags, Instantaneous and Phase primary
Current, Trip Counter (TC), Fault Date & Time.
Press the down arrow key (- /) the relay will display as
follows.
