ASL INTERCOM Enchorus ENC 1201 User Manual

Conguring the Unit via its Web Interface
Transmitters (Outputs)
ENC 1201 Version 1.0 Page 37
4.6 Transmitters(Outputs)
The “Transmitters” menu structure is very similar to that of the “Receivers” menu. This
is where you can view and edit the ENC 1201’s outputs. The dropdown menu provides
access to three sections: General, Metering and Labels.
4.6.1 Transmitters(Outputs)>General
This pane allows you to edit basic settings for the ENC 1201’s physical outputs.
The ENC 1201 has 4 Line inputs. Their settings are displayed and can be edited on the
“Line 1-2” and “Line 3-4” tabs.
All outputs provide the same parameters.
Line1-2andLine3-4
Signal Source
“Signal Source” displays the audio source for that output. Sources can be assigned under
“I/O” (p.43).
Options
Click the buttons in this row to activate or switch o the corresponding functions. Active
functions are displayed on an orange background.
Mute Clicking [Mute] (orange) will switch that channel o.
EQ All of the ENC 1201’s physical outputs are equipped with an equalizer. Click this
button to switch the associated equalizer on (orange) of o (gray).
Edit EQ [Edit EQ] is always displayed in orange. Clicking this button opens a pop-up win-
dow where you can set the equalizer. See “EQ” (p.33).
