Introduction
General Considerations
ENC 1201 Version 1.0 Page 5
1 Introduction
1.1 General Considerations
Thank you for choosing an Enchorus ENC 1201 audio interface.
The devices of the Enchorus series allow you to create a professional and exibly scalable
Dante™ network for live applications, recording studios, installations and more.
These versatile audio devices meet the most demanding audio requirements. They can be
positioned close to the sources and destinations and make separate DI boxes obsolete.
They come in handy for frequent and time-critical setup applications and are highly
intuitive to congure.
1.1.1 ENC 1201 Features
The ENC 1201 provides the following features:
• 8x XLR microphone inputs, with individually switchable +48V phantom power
• 32-bit microphone pre-ampliers
• 4-way splitter for each microphone input, with individual gain settings, 4-band EQ and
phase reverse
• 4x line outputs (1x RJ45)
• Conguration via a built-in web interface
• 32x Dante™ inputs and outputs
• 2x Dante™ LAN ports (switched or redundant mode)
• Redundant power supply
• 8x built-in 16-in-2 mixers
• Built-in audio matrix
• Equalizers on all physical inputs and outputs:
Low-cut (12, 18, 24, 36dB/octave) with adjustable frequency
3 parametric EQ bands (low-pass, high/low shelf, peaking)
• Chassis: half-rack 19”/1U with rubber bumpers, stackable (depth: 225mm)
• Sample rates: 44.1/48/88.2/96/176,4/192kHz
• Word length: 16, 24, 32 bits (transparent)
• Rock-solid synchronization across several switches
• Supports 100Mbps and 1Gbps, requires no proprietary network infrastructure
• Easy and exible handling (plug & play)
