6.2.2 V2000 Dynamic Commissioning
All V2000 dynamic commissioning is done using the V2000 Dynamic Configuration Tool. The tool is
launched from within the System Configuration Tool or as standalone.
V2000 System Surveillance
Overview:
• Input Surveillance – Monitors the audio connection between VIPEDIA-12 and V2000 units by detecting
a tone generated from Vipedia.
• Amplifier Output Surveillance – Monitors amplifier health by detecting a configurable internal tone.
• Loudspeaker line monitoring: (one of three possible methods)
o DC End of Line (DC-EOL) – Detects resistors fitted at the end of each loudspeaker spur.
o Impedance Line Monitoring – Monitors the impedance of the loudspeaker line. A configurable
internal tone is sent from the V2000 down the speaker line to provide the voltage required for
measurement. (High frequency tone only) (Feature not yet available).
o Loop Return Line Monitoring – Detects a configurable internal tone sent out the amplifier’s A
output which is looped back to the B output. (Feature not yet available)
• Earth Leakage – Monitors the loudspeaker line’s connection to ground. A configurable internal tone is
sent from the V2000 down the speaker line to provide the voltage required for measurement. (Low
frequency tone only)
Surveillance Tone Types:
• VIPEDIA-12 audio output tone – Configured using the VIPEDIA-12 Dynamic Configuration Tool.
(See Section 6.2.1.2 VIPEDIA-12 Surveillance Generator Commissioning)
Required for Input Surveillance.
• Internal V2000 tone (Low or High frequency) – Configured using the PAVA System Configuration
Tool and the V2000 Dynamic Configuration Tool.
(See Section 6.2.2.2 V2000 System Surveillance Commissioning)
Required for:
o Amplifier Surveillance
o Impedance Line Monitoring (High frequency only) (Feature not yet available)
o Loop Return Line Monitoring (Feature not yet available)
o Earth Leakage (Low frequency only)
• V2000 DC offset is an automatic feature.
Required for DC End of Line.
