ASL INTERCOM V2000 User Manual

V2000 User’s Manual
U-0623-0383.docx – Issue: 05 complete, approved – 17/12/15
Page 5 of 36
1 Introduction
This guide provides guidance on the configuration, basic operation, and troubleshooting of the V2000
Amplifier Mainframe.
This guide will also provide some basic information on VIPEDIA-12 Router configuration, required for full
V2000 functionality.
The term ‘PAVA system’ will be used when referring to the system as a whole (VIPEDIA-12 + V2000 + other
related hardware).
The diagram below provides an overview of the configuration and commissioning process.
Summary of Task Section Page
Safety and Precautions
Read the safety and precautions instructions and guidelines 2 6
Requirements
1. Gather documentation, software tools, and set up PC 3.2 10
2. V2000 installed 10
No installation instructions are provided in this document. Refer to V2000
Installation Guide (U-0623-0291)
3. Power up the rack, MAINS power only 10
4. Configure all VIPEDIA-12 IP addresses 11
V2000 IP Configuration
1. Ensure all V2000 Ethernet connections are removed. 5 12
2. Power up the first V2000 and configure IP address using the ASL Transfer Tool
12
3. Configure IP addresses of remaining V2000s in turn 13
4. Connect all V2000 Ethernet connections to the network. 13
5. Power up all V2000s (MAINS only) 13
V2000 static configuration 1. Load the VIPEDIA-12 PAVA static configuration into the System Configuration
Tool
6 15
2. Add V2000s to the PAVA system configuration 15
3. Add battery if battery backup system used 15
4. Configure the frame settings 15
5. Configure the amplifiers and define the surveillance methods used 16
Upload static configuration Upload the static configuration to all V2000s and VIPEDIA-12s using the ASL
Transfer Tool
6.1.3 17
VIPEDIA-12 Dynamic
Commissioning
1. Commission VIPEDIA-12 output limiter 6.2.1 18
2. Commission VIPEDIA-12 output clipper 18
3. Commission VIPEDIA-12 output surveillance generator 19
V2000 Dynamic Commissioning
1. Commission V2000 input surveillance 6.2.2 22
2. Commission V2000 amplifier output surveillance 22
3. Commission V2000 DC-EOL surveillance 22
4. Commission V2000 earth leakage surveillance 22
5. Backup dynamic configuration 24
Rack Power (BATTERY)
1. Power up the rack BATTERY power 4.2.2 10
2. Switch on V2000 BATTERY supply 10
