AD-3100 Drawer Type Incubator Operation Manual Rev. 4
ASTEC CO., LTD.
12
7. Parts Description
(1) Incubation Drawer Chamber
(2) Incubation Drawer Chamber
(3) Incubation Drawer Chamber
(4) Incubation Drawer Chamber
(5) Control Panel
(6) Drawer Knob
(7) Alarm and Analog Outputs
Power Monitoring Output
(8) CO
2
Inlet Port
(9) N
2
Inlet Port
(10) Circuit Breaker
(11) Power Switch
(12) AC Power Inlet
(13) Gas Sampling Port
(14) Chamber Lid Latch
(15) Utility Port
(16) Gas Sampling Port
(17) Aluminum block chamber
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
(16)
Hand-Held Chamber
