ASTRO VG-877 - SHDMISW4 [20 H 99 H ]: HDMI SW Data Setting

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
199
2.106 SHDMISW4 [20H 99H ] : HDMI SW data setting
Function : This command gets HDMI SW data of the indicated program No. In case, program
No.0, the data is saved in buffer RAM temporally. In case, NO.9999, the data is
saved in command work RAM.
Sequence : TYPE 2
Command ：
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
SHDMISW4
2 BYTE
20H 99H
Program NO
1 - 4
BYTE
"0" - "1000","9999"
1 BYTE
2CH (Delimiter)
HDMI 1 Mode
1 BYTE
"0"= selector, "1"= all outputs
,
1 BYTE
2CH (Delimiter)
HDMI 1 InSel
1 BYTE
"0" - "1"
,
1 BYTE
2CH (Delimiter)
HDMI 1 OutSel
1 BYTE
"0" - "7"
Note) This command is active when Mode
is selected as Selector.
,
1 BYTE
2CH (Delimiter)
HDMI 2 Mode
1 BYTE
"0"= selector, "1"= all outputs
,
1 BYTE
2CH (Delimiter)
HDMI 2 Input Select
1 BYTE
"0" - "1"
,
1 BYTE
2CH (Delimiter)
HDMI 2 Output Select
1 BYTE
"0" - "7"
Note) This is active when Mode is selected
as Selector.
ETX
1 BYTE
03H
Fig 2-106-1
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
