ASTRO VG-877 - LLGRP5 [20 H A0 H]: Large Group Data Readout

Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
205
2.111 LLGRP5 [20H A0H] : Large group data readout
Function : This command reads out indicated large group No. data.
Sequence : TYPE3
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
LLGRP5
2 BYTE
20H A0H
Large group NO
1-2 BYTE
"1"-"99"
ETX
1 BYTE
03H
Fig 2-111-1
Data :
STX
1 BYTE
02H
TRDT
1 BYTE
10H
Large group NO
1-2 BYTE
"1"-"99"
,
1 BYTE
2CH (Delimiter)
Character number of
large group name.
1-2 BYTE
"1"-"20"
,
1 BYTE
2CH (Delimiter)
Large group name
20 BYTE
20 ASCII characters (When the string contains
fewer than 20 characters, enter spaces after the
characters to bring the number of characters up to
20)
,
1 BYTE
2CH (Delimiter)
#1
Slot No.
1-2 BYTE
"0"-"11"
,
1 BYTE
2CH (Delimiter)
Board Type
1 BYTE
"1"-"5"
"1"=HDMI
"2"=HDMI & VGA
"3"=TVAnalog(YPbPr)
"4"=TVAnalog(D5)
"5"=Scart
Note) 0 is invalid.
,
1 BYTE
2CH (Delimiter)
#1-1
Execution sequence No.
1-2 BYTE
"1"-"12"
,
1 BYTE
2CH (Delimiter)
Small group No.
1-2 BYTE
"0"-"99" ("0"=unregistered)
,
1 BYTE
2CH (Delimiter)
#1-2
Execution sequence No.
1-2 BYTE
"1"-"12"
,
1 BYTE
2CH (Delimiter)
Small group No.
1-2 BYTE
"0"-"99" ("0"=unregistered)
,
1 BYTE
2CH (Delimiter)
#1-3
Execution sequence No.
1-2 BYTE
"1"-"12"
,
1 BYTE
2CH (Delimiter)
Small group No.
1-2 BYTE
"0"-"99" ("0"=unregistered)
,
1 BYTE
2CH (Delimiter)
#4
Slot No.
1-2 BYTE
"0"-"11"
,
1 BYTE
2CH (Delimiter)
PC
VG
STX～ETX
STX+TRDT+DATA+ETX
ACK or
STX+ESTS+ERROR CODE+ETX
