Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
201
2.108 STPKEY4 [20H 9BH] : Key information of Timing and
Pattern data registration
Function : This command registers key information of Timing and Pattern of the indicated
program No. In case, program No.0, the data is saved in buffer RAM temporally. In
case , No.2001-2010, the data is saved in the Internal memory. In case, NO.9999,
the data is saved in command work RAM.
Sequence : TYPE 2
Command :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
STPKEY4
2 BYTE
20H 9BH
Program NO
1 - 4 BYTE
"0"-"1000","2001"-"2010","9999"
,
1 BYTE
2CH (Delimiter)
Timing Key No
1 - 2 BYTE
"1"-"12"
,
1 BYTE
2CH (Delimiter)
Timing FREQ No
1 - 2 BYTE
"1"-"10"
,
1 BYTE
2CH (Delimiter)
Pattern Key No
1 - 2 BYTE
"1"-"10"
ETX
1 BYTE
03H
Fig 2-108-1
This command is only for VG-881.
PC
VG
STX～ETX
ACK or
STX+ESTS+ERROR CODE+ETX
