Chapter 6 EXAMPLES OF USAGE
471
Level 14 = 100%
0×31
“1”
0×30
“0”
0×30
“0”
0×30
“0”
Delimiter
0×2C
“, “
Level 15 = 100%
0×31
“1”
0×30
“0”
0×30
“0”
0×30
“0”
ETX
0×03
Note) ACK or the error status is received from the VG generator here.
ACK is received if the data has been transferred successfully.
6.3.4 Settings established using program data execution command
Program data execution: Command [24H 20H]
Parameters:
Setting item
Setting value
Binary
ASCII
STX
0×02
VG4CMD
0×FD
EXPDN4
0×24
“$”
0×20
Program number
0×31
“1”
Delimiter
0×2C
“, “
Execution mode (Pattern)
0×32
“2”
ETX
0×03
Note) ACK or the error status is received from the VG generator here.
ACK is received if the data has been transferred successfully.
6.3.5 Settings established using program data execution command
(Buffer RAM)
Buffer RAM program data execution: Command [24H 22H]
Parameters:
Setting item
Setting value
Binary
ASCII
STX
0×02
VG4CMD
0×FD
EXBN4
0×24
“$”
0×22
“““
ETX
0×03
Note) ACK or the error status is received from the VG generator here.
ACK is received if the data has been transferred successfully.
