2.125 LTM4 [20H B0H] :Transmission Mode data aquisition
Function : This command gets Transmission Mode data of the indicated program No. In case
program NO.1001 to 2000, the VG original data is read out. In case ,NO.9999, the
data is read out from command work RAM.
Sequence : TYPE 3
Parameter :
STX
1 BYTE
02H
VG4CMD
1 BYTE
FDH
LARC4
2 BYTE
20H B0H
Program NO
1-4 BYTE
"0"-"2000","9999"
ETX
1 BYTE
03H
Fig 2-125-1
Data :
STX
1 BYTE
02H
TRDT
1 BYTE
10H
PacketType
1 BYTE
"0"-"9"
,
1 BYTE
2CH (Delimiter)
Interval
1 BYTE
"0"-"20"
ETX
1 BYTE
03H
Fig 2-125-2
PC
VG
STX～ETX
STX+TRDT+ﾃﾞｰﾀ+ETX
ACK or
STX+ESTS+ERROR CODE+ETX
