DynamicRange
1 BYTE
"0"=100% "1"=200% "2"=400%
,
1 BYTE
2CH (Delimiter)
BitDepth
1 BYTE
"0"=8bit "1"=10bit "2"=12bit
,
1 BYTE
2CH (Delimiter)
Payload H YSampling
1 BYTE
"0"-"1"
,
1 BYTE
2CH (Delimiter)
Manual Payload ID
“0”=Auto, “1”=Manual
,
1 BYTE
2CH (Delimiter)
Payload ID Byte1
1-2 BYTE
“00”-“FF”
,
1 BYTE
2CH (Delimiter)
Channel Assignment 1
1 BYTE
“0”=1,
“1”=2,
“2”=3,
“3”=4
Below is available only for VG-876.
"4"=5
"5"=6
"6"=7
"7"=8
,
1 BYTE
2CH (Delimiter)
Channel Assignment 2
1 BYTE
“0”=1,
“1”=2,
“2”=3,
“3”=4
Below is available only for VG-876.
"4"=5
"5"=6
"6"=7
"7"=8
Channel Assignment 8 *
1 BYTE
"0"=1
"1"=2
"2"=3
"3"=4
"4"=5
"5"=6
"6"=7
"7"=8
,
1 BYTE
2CH (Delimiter)
Audio Link
1 BYTE
"0"=Add Channel
"1"=Copy Link1
ETX
1 BYTE
03H
Fig 2-115-2
* The number after Channel Assignment 3 is only available for VG-876.
