Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
237
(When L/R is OFF)
,
1 BYTE
2CH (Delimiter)
Level L
(When L/R is ON)
1-3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
Level R
(When L/R is ON)
1～3 BYTE
"0"-"100"%
,
1 BYTE
2CH (Delimiter)
OutputMode
1 BYTE
"0"=3D Structure "1"=Frame Sequential
,
1 BYTE
2CH (Delimiter)
LRDisp
1 BYTE
"0"=OFF
"1"= Display on top
"2"= Display in center
,
1 BYTE
2CH (Delimiter)
LRBlackBack
1 BYTE
"0"=Not use "1"=Use
,
1 BYTE
2CH (Delimiter)
SubSampling
1 BYTE
"0"=Not use "1"=Use
ETX
1 BYTE
03H
Fig 2-131-2
