Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
239
About output terminal code:
*VG-870, 871 and 880
Code
Terminal
0
PC-BNC
1
PC-DSub
2
DVI-A
3
DVI-D
4
VBS
5
BNC
6
S-Connector
7
D-Connector
8
TV-DSub
9
Scart-1
10
Scart-2
11
HDMI-1
12
HDMI-2
13
DVI-D1
14
DVI-D2
15
LVDS-1
16
LVDS-2
17
LVDS-3
18
LVDS-4
19
Parallel-1
20
Parallel-2
21
Parallel-3
22
Parallel-4
23
DP1
24
DP2
25
TV-DVI Digital
26
iTMDS-1
27
iTMDS-2
28
VbyOne-1
29
VbyOne-2
30
iTMDS-Quad1,2
31
iTMDS-Quad3,4
32
SDI-1,2
33
SDI-3,4
Fig. 0-2
* VG-882 and 883
Code
Terminal
50
HDMI 1
VG-882 and 883
51
HDMI 2
52
HDMI 3
53
HDMI 4
54
VGA
Only
VG-882
55
YPbPr
56
D5
57
CVBS
58
Y/C
59
Scart
Fig. 0-3
