Chapter 4 INDIVIDUAL FORMATS FOR CONTROL COMMANDS
Example) available case：in case RGB is set by 51 steps in the range of 255, the palette 0
should be set as “black”.
Control code（02H 03H）： total 2Byte
Distinguish code（FDH）： 1Byte
Command code（28H 4FH）： total 2Byte
Parameter：693Byte
Total 698Byte
Since this is less than 1024 bytes, it is okay to transfer.
