352
(2) Analog data
STX
1 byte
02H
TRDT
1 byte
10H
Horizontal timing
30 bytes
Refer to Fig. 4-1-2.
Delimiter
1 byte
“, “
Vertical timing
34 bytes
Refer to Fig. 4-3-2.
Delimiter
1 byte
“, “
Analog output
condition
20 bytes
Refer to Fig. 4-5-3.
Delimiter
1 byte
“, “
Graphic color
12 bytes
Refer to Fig. 4-7-2.
Character
8 bytes
Refer to Fig. 4-7-3.
Crosshatch
8 bytes
Refer to Fig. 4-7-4.
Dot
8 bytes
Refer to Fig. 4-7-5.
Circle
1 byte
Refer to Fig. 4-7-6.
Burst
5 bytes
Refer to Fig. 4-7-7.
Window
22 bytes
Refer to Fig. 4-7-8.
Optional pattern 1
1 byte
Refer to Fig. 4-7-9.
Optional pattern 2
1 byte
Refer to Fig. 4-7-10.
Delimiter
1 byte
“, “
Color bar
26 bytes
Refer to Fig. 4-7-11.
Delimiter
1 byte
“, “
Gray scale
49 bytes
Refer to Fig. 4-7-12.
Delimiter
1 byte
“, “
Half tone
17 bytes
Refer to Fig. 4-7-13.
ETX
1 byte
03H
Fig. 4-9-3
