(5) Circle data
STX
1 byte
02H
TRDT
1 byte
10H
Circle format
1 byte
“0” to “6”
Aspect ratio H
3 bytes
Fixed at “0” * This function cannot be used.
Aspect ratio V
3 bytes
Fixed at “0” * This function cannot be used.
ETX
1 byte
03H
Fig. 4-29-6
(6) Burst data
STX
1 byte
02H
TRDT
1 byte
10H
Burst format
1 byte
“0” to “3”
Interval
2 bytes
“01” to “99”
Step
2 bytes
“01” to “99”
ETX
1 byte
03H
Fig. 4-29-7
(7) Window data
STX
1 byte
02H
TRDT
1 byte
10H
Window mode
1 byte
“0” = %, “1” = dot
H width
4 bytes
% = “0001” to “1000” (0.1 to 100.0%)
dot = “0001” and above
V width
4 bytes
% = “0001” to “1000” (0.1 to 100.0%)
dot = “0001” and above
R
3 bytes
“000” to “255”
G
3 bytes
“000” to “255”
B
3 bytes
“000” to “255”
Window color (TTL)
1 byte
“0” = None, “1” = R, “2” = G, “3” = RG, “4” = B,
“5” = RB, “6” = GB, “7” = RGB
Window half tone
1 byte
“0” = None, “1” = RH, “2” = GH, “3” = RHGH, “4”
= BH, “5” = RHBH, “6” = GHBH, “7” = RHGHBH
Format
1 byte
“0” to “F”
The coordinate data of format “E” is not
supported by the terminal commands.
Flicker interval
1 byte
“0” to “7”
ETX
1 byte
03H
Fig. 4-29-8
(8) Optional pattern 1 data
STX
1 byte
02H
TRDT
1 byte
10H
Optional pattern code
2 bytes
“00” to “BF”
ETX
1 byte
03H
Fig. 4-29-9
(9) Optional pattern 2 data
STX
1 byte
02H
TRDT
1 byte
10H
Optional pattern code
2 bytes
“00” to “BF”
ETX
1 byte
03H
Fig. 4-29-10
