Chapter 2 INDIVIDUAL FORMATS FOR VG CONTROL COMMANDS
49
(16) Checker data
Type
1 byte
“1” = DOT×DOT
“2” = BLK×BLK
“3” = SubPixel
,
1 byte
2CH (Delimiter)
Xsize of dot × dot
1 byte
“1” to “8”
,
1 byte
2CH (Delimiter)
Ysize of dot × dot
1 byte
“1” to “8”
,
1 byte
2CH (Delimiter)
Number of BLK × BLK
blocks in X direction
1 or 2 bytes
“2” to “16”
,
1 byte
2CH (Delimiter)
Number of BLK × BLK
blocks in Y direction
1 or 2 bytes
“2” to “16”
,
1 byte
2CH（Delimiter）
Checker color assignment
1 byte
"0"=OFF(Default color)
"1"=ON(Refer CHECKER color data)
,
1 byte
2CH（Delimiter）
SubPixelSize X
1 byte
"0" to "3"
,
1 byte
2CH（Delimiter）
SubPixelSize Y
1 byte
"0" to "3"
,
1 byte
2CH（Delimiter）
Reserve1
1 byte
"0" FIX
,
1 byte
2CH（Delimiter）
Reserve2
1 byte
"0"FIX
,
1 byte
2CH（Delimiter）
Color0 R
1 to 5 bytes
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Color0 G
1 to 5 bytes
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Color0 B
1 to 5 bytes
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Color1 R
1 to 5 bytes
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Color1 G
1 to 5 bytes
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Color1 B
1 to 5 bytes
"0" to "65535"
,
1 BYTE
2CH（Delimiter）
Edit Bit Mode
1 to 2 bytes
"8" to "16"
Fig. 2-13-17
(17) Optional pattern data
Internal optional pattern
code
1 to 3 bytes
“1” to “200”
,
1 byte
2CH (Delimiter)
User optional pattern
code
1 to 3 bytes
“1” to “200”
,
1 byte
2CH (Delimiter)
Image data code
1 to 3 bytes
“1” to “200”
,
1 byte
2CH (Delimiter)
Optional pattern type
1 byte
“0” = Internally fixed, “1” = Created by user,
“2” = Image data
,
1 byte
2CH（Delimiter）
Movie data code
1 to 3 bytes
"1" to "200"
Fig. 2-13-18
