Super Sprint
Table of Contents
1 Set-Up
How to Use This Manual . 1-1
Inspecting the Game . 1-4
Moving the Super Sprint Cabinet. 1-4
Positioning the Display Enclosure. 1-4
Control and Switch Locations. 1-6
Power On/Off Switch. 1-6
Volume Control. 1-6
Coin Counter ^. 1-6
Self-Test Switch . 1-6
Coin and Game Option Settings. 1-6
2 Game Play
Introduction.... 2-1
Operating Modes. 2-2
Play Mode. 2-2
High Score Mode. 2-2
Maximizing Earnings . 2-2
Average Game Times/Average Time Between Coin Drop. 2-3
Self-Test Mode . 2-3
3 Self-Test
RAM/Interrupt/ROM Test. 3-2
6502 Processor Test. 3-2
Pedal Test. 3-4
Calibration Procedure . 3-4
LetaTest. 3-4
Alphanumeric Test. 3-4
Scrolling Playfleld Test . 3-5
Motion Object Test. 3-5
Motion Object Height Test. 3-5
Color Bar Test. 3-6
Color Purity Test . 3-6
Convergence Test. .. 3-6
Accounting Information. 3-6
Reset Saved Information Screen. 3-7
Switch Settings. 3-7
4 Maintenance
Preventive Maintenance . 4-2
Preventive Maintenance Intervals . 4-2
Opening the Control Panel and Removing the Speakers. 4-2
Cleaning the Pushbutton Lbaf Switches. 4-2
Cleaning the Coin Mechanism. 4-4
Cleaning the Interior Components. . .,. 4-4
Steering Wheel Controls . 4-4
Lubricating the Steering Wheel Controls /. 4-4
Corrective Maintenance . 4-4
Removing the Pushbutton Leaf Switches. 4-4
Removing the Steering Wheel. 4-4
Disassembling the Steering Wheel. 4-4
Reassembling the Steering Wheel. 4-6
Removing the Foot Pedal Controls. 4-6
Removing the Game PCBs. 4-6
Video PCB .'. 4-6
CPU PCB . 4-6
Removing the Video Display. 4-8
Replacing the Video Display. 4-9
5 Illustrated Parts List
See List of Illustrations that follows.
