13 Rev. 00

2 GENERAL DESCRIPTION

2.1 Overall dimensions and technical data

The overall dimensions of the complete crimping machine GAMMA are shown in fig. 2-1. The

measures are in millimeters.

! NOTE

While installing ensure 100cm clearance all around the

machine to allow user's free movement.

The following data refer to the machine technical characteristics, performance and capacity.

— Machine height: 1308 mm;

— Machine width: 835 mm (1946 mm with support profiles);

— Machine lenght: 786 mm (1221 mm with support profiles);

— Machine weight: 350 kg;

— Air supply: 0,7 MPa (7 bar);

— Air absorption: 9 l/corner;

— Max operating stroke: 350 mm;

— Knives operating stroke: max 12 mm;

— Sound-intensity level: 73 dB(A).
