34 Rev. 00
6.3 Protective devices
The machine is equipped with fixed guards and interlocking protective devices (safety guards). The
fixed guards are made of sheet iron. The interlocking protective device (safety guard) is made of
glass and sheet iron in order to allow the visibility of the production process also by closed safety
guard. The interlocking protective device is pneumatic. The opening of the safety guard gives a stop
command to the pedal for moving the bracing clamp while the other monostable pedal remains
operating.
! ! ! WARNING ! ! !
Do not interfere in the area of the bracing clamp
movement, by opening of safety guard the clamp goes
forward automatically without re-enterring in the machine
bed.
6.4 Personal Protection Equipment
The user is not under obligation to have some personal protection equipment during the operations
on the machine.
6.4 Residual risks
This section is intended to draw attention to the residual risks related to the operations to be carried
out by the user/operator.
— during the crimping (movement of knives and vertical cylinder) still persists the crush hazard
between the vertical cylinder and the profile; the operator must follow the following instructions
(the movement is controlled by a monostable pedal, max. stroke of clamp is 60 mm):
• before crimping the plunger of vertical cylinder must be not more than 4 mm from the upper
surface of profile,
• in case of test without profile for the setup of the machine the operator must position the
vertical cylinder and move it left far from the work area;
— during the crimping (movement of knives and vertical clamp) still persists the crush hazard
between the knives and the profile (in particular when the operator makes crimping tests with
the opened protective devices); therefore the user must never interfere inside the knives area.
(the movement is controlled by a monostable pedal, max. stroke of knives is 12 mm);
