16 Rev. 00
3 SPECIFICATIONS
3.1 General Description
The machine is designed and constructed for crimping and correct assembly of aluminium profiles
through the pneumatically controlled system.
The machine operating is semiautomatic, the machining cycle of various units are manual controlled
by user who always stays outside danger's area.
The macchina is equipped with the foot pedals for the operation control during the machining cycle.
Fig. 3.1 shows the various parts of the crimping machine.
See section 5 for a detailed description of the control devices.
See section 6 for a detailed description of the safety devices.
