Description
1
Menu button
2
Navigation knob (rotate knob), accept (press knob)
3
Back button
7 Controller Interface
7.1 User Interface
MENU
15:23
12°
19,0°
19.5
ECO
19,0°
21.5
ECO
OFF
" 2 heating circuit version
+ domestic hot water (DHW)
Zone 1 Zone 2
MENU
15:23
12°
19,0°
21,5
ECO
OFF
" 1 heating Circuit version
+ domestic hot water (DHW)
1
2
3
7 September 2017 7 September 2017
Installation and Operating Manual "1821- EN"
Alféa Extensa Duo A.I. Heat Pump
