8.2 Installed options
Installed options are congured during commissioning (see page 42).
However, you can modify them by accessing the "Installed Options" menu.
Name of Appliance
- Choose the appliance's power.
Electrical backup
- Choose the electrical backup power.
Boiler connection
- If the electrical backup is set to "No", you can then set the boiler connection to "Yes".
- If a power setting is applied to the electrical backup, the boiler connection setting
remains set to "No" and cannot be changed.
Number of Circuits
- Choose the number of circuits.
Cooling
- If the installation is tted with cooling function, choose the zone(s):
None / Area 1 / Area 2 / Area 1 and 2.
Name of Appliance
-- KW
Number of circuits 2
3 KWElectrical back-up
Area 1Cooling
Boiler connection No
Installed options
Complete
8.3 Hydraulic conguration
8.3.1 Heating / Cooling
- Choose the heating zone to congure.
Hydraulic conguration
Area 1 (Direct circuit)
Area 2 (Mixed circuit)
Hot water
Some settings (or menus) might not be displayed. They are dependent on the installation's conguration (and installed options).
Installed options
Hydraulic conguration Area 1
Installation and Operating Manual "1821- EN" - 51 -
Alféa Extensa Duo A.I. Heat Pump
