Designations
Reference Compressor
A1 Dryer
M1 Compressor motor
M3 Fan motor cubicle
M4 Fan motor, oil cooler
M5 Fan motor, aftercooler
PT20 Pressure sensor, delivery air
TT11 Temperature sensor, element outlet
TT90 Temperature sensor, dew-point (only for Full-Feature)
Y1 Loading solenoid valve
Reference Starter cubicle
1X1/1X5 Terminal strips
F1/F11 Fuses
K11 Auxiliary contactor for dryer (only for Full-Feature)
K21 Main contactor
T1 Transformer
U1 Frequency converter
X103/X122 Connectors
Reference Control module
I Start button
K01 Auxiliary relay, fan motor
K02 Auxiliary relay
K03 Auxiliary relay
K04 Auxiliary relay, load/unload
K05 Auxiliary relay, VSD
K06 Auxiliary relay, dryer control
K07 Auxiliary relay, manual/automatic operation
K08 Auxiliary relay, general warning
K09 Auxiliary relay, general shut-down
O Stop button
S3 Emergency stop button
Reference Optional equipment
B1 Electronic Water Drain (EWD)
PDS11 Dp switch for integrated DD filter
PDS12 Dp switch for integrated PD filter
S10 Main power isolating switch
