• Press the arrow down key (1) to find out which service plans were carried out previously; the
following screen appears:
‘Previous Timer’
‘Level’ A B
‘hrs’ 4008
.
F1 F2 F3
• The screen shows that service plans A and B were carried out at 4008 running hours.
• Stop the compressor, switch off the voltage and carry out the service operations related to
plans A, B and C; see section Preventive maintenance schedule.
• Switch on the voltage and scroll to the ‘Next Timer’ service screen.
• Press the ‘Rset’ button (F3). Confirm the question for resetting.
The ‘Rset’ button only appears when the ‘Next Timer’ level is almost reached.
After pressing the arrow down key in the ‘Service Timer’ screen, the ‘Life Time’ hours are
shown, i.e. the number of hours elapsed since initial programming ex-factory. This timer is
not taken into account.
3.21 Saved data menu
Control panel
Function
To call up some compressor data saved by the regulator. These data are:
• Last shut-down data
• Last emergency stop data
Procedure
Starting from the Main screen:
• Press the key ‘Menu’ (F1)
• Press the arrow down key (1) until the option ‘Saved Data’ is followed by a horizontal arrow.
• Press the tabulator key (2) to activate the menu.
• The list of last shut-down and emergency stop cases is shown.
Instruction book
API161475 41
