Function
To modify the hour intervals for the service levels.
Service plans
The service actions to be carried out are grouped in plans called Service level A, B, C or D.
When reaching an interval, a message will appear on the screen indicating which Service plans
are to be carried out.
Always consult your Atlas Copco Customer Centre if any timer should be changed. The
intervals must not exceed the intervals below and must coincide logically.
Programmed service plan intervals (typical example)
Service plans Intervals
Service plan A Each 4000 running hours
Service plan B Each 4000 running hours
Service plan C Each 8000 running hours
Service plan D Each 24000 running hours
The regulator will not accept new values beyond the limits. Press the key ‘Lim.’ to check the
limits for the parameter. Consult Programmable settings for the most important settings.
Resulting service actions to be carried out
Service actions according
to
At
Service plan A and B 4000 running hours
Service plan A, B and C 8000 running hours
Service plan A and B 12000 running hours
Service plan A, B and C 16000 running hours
Service plan A, B, C and D 24000 running hours
... ...
Procedure
Starting from the Main screen (see Main screen menu):
• Press the ‘Menu’ key (F1).
• Press the arrow down key (1) until ‘Modify Params’ is followed by a horizontal arrow.
• Activate the menu by pressing the tabulator key (2).
• Press the arrow down key (1) until ‘Service Plan’ is followed by a horizontal arrow.
• Press the tabulator key (2): a screen similar to the one below will appear:
Instruction book
32 API161475
