Minimum
setting
Factory
setting
Maximum
setting
Unloading pressure (125 psi compressors) psig 58 125 129
Unloading pressure (150 psi compressors) bar(e) 4 10.3 10.6
Unloading pressure (150 psi compressors) psig 58 150 153.5
Unloading pressure (175 psi compressors) bar(e) 4 12 12.3
Unloading pressure (175 psi compressors) psig 58 175 178.4
Loading pressures
Loading pressure (7.5 bar compressors) bar(e) 4 6.4 7.2
Loading pressure (7.5 bar compressors) psig 58 92.8 104.5
Loading pressure (8.5 bar compressors) bar(e) 4 7.4 8.2
Loading pressure (8.5 bar compressors) psig 58 107 119
Loading pressure (10 bar compressors) bar(e) 4 8.9 9.7
Loading pressure (10 bar compressors) psig 58 129.1 140.5
Loading pressure (13 bar compressors) bar(e) 4 11.9 12.7
Loading pressure (13 bar compressors) psig 58 172.6 184
Loading pressure (100 psi compressors) bar(e) 4 6.3 7.1
Loading pressure (100 psi compressors) psig 58 91.4 103
Loading pressure (125 psi compressors) bar(e) 4 8 8.8
Loading pressure (125 psi compressors) psig 58 116 127.5
Loading pressure (150 psi compressors) bar(e) 4 9.7 10.5
Loading pressure (150 psi compressors) psig 58 140.7 152.5
Loading pressure (175 psi compressors) bar(e) 4 11.4 12.2
Loading pressure (175 psi compressors) psig 58 165.3 177
Parameters
Minimum
setting
Factory
setting
Maximum
setting
Motor running time in star sec 5 10 10
Load delay time (star-delta) sec 0 0 10
Number of motor starts starts/day 0 240 240
Minimum stop time sec 10 20 30
Programmed stop time sec 0 3 20
Power recovery time (ARAVF) sec 10 10 3600
Restart delay sec 0 0 1200
Communication time-out sec 10 30 60
Instruction book
2920 7180 30 67
