– Disconnect the battery. Refer to ⇒ Electrical Equipment; Rep.
Gr. 27 ; Battery; Battery, Disconnecting and Connecting .
– Engage the 4th gear on versions with a manual transmission.
– Carefully pull the engine cover off the retaining pins one after
the other in direction of -arrows-. Do not remove the engine
cover on one side or in a jerking manner.
WARNING
The Cooling System Is Under Pressure When the Engine Is
Warm. There Is a Risk of Scalding Due to Hot Steam and Hot
Coolant.
Scalding the Skin and Other Parts of the Body Is Possible.
– Wear safety gloves.
– Wear protective eyewear.
– Reduce the pressure by covering the coolant expansion tank
cap with a cloth and carefully opening it.
– Open the coolant expansion tank cap -1- by releasing the
catch in direction of -arrow- if necessary.
– Remove the front wheels. Refer to ⇒ Suspension, Wheels,
Steering; Rep. Gr. 44 ; Wheels, Tires .
– Remove the noise insulation. Refer to ⇒ Body Exterior; Rep.
Gr. 66 ; Noise Insulation; Noise Insulation, Removing and In‐
stalling .
– Remove the left and right wheel spoiler as well as the right
front wheel housing liner. Refer to ⇒ Body Exterior; Rep. Gr.
66 ; Wheel Housing Liner; Front Wheel Housing Liner, Re‐
moving and Installing .
– Equipment version: disconnect the connector -2- for the Intake
Air Switch-Over Valve - N335- and remove the water drain
-1- downward in direction of -arrow-.
Audi A4 2015 ➤ , Audi A4 China 2016 ➤ , Audi A5 2016 ➤
4-Cylinder Direct Injection 2.0L 4V TFSI Engine (EA 888 Generation III) - Edition 11.2019
1. Engine, Removing and Installing 5
