10 – Engine Assembly
1 Engine, Removing and Installing
⇒ “1.1 Engine, Removing”, page 4
⇒ “1.2 Engine, Securing to Engine and Transmission Holder”,
page 31
⇒ “1.3 Engine, Installing”, page 31
1.1 Engine, Removing
⇒ “1.1.1 Engine, Removing, Vehicle with Generator”, page 4
⇒ “1.1.2 Engine, Removing, Vehicle with Starter Generator”, page
16
1.1.1 Engine, Removing, Vehicle with Gener‐
ator
Special tools and workshop equipment required
♦ Engine Support Bridge - 10-222A-
♦ Engine Support Bridge - Spindle - 10-222A/11-
♦ Engine Sling - 2024A-
♦ Shop Crane - VAS6100-
♦ Engine Support Bridge Adapter - 3147-
♦ Ring Wrench 7-Piece Set - 3337-
♦ Torque Wrench 1332 Insert - Ring Wrench - 16mm -
VAG1332/14-
♦ Shop Crane - VAS6100-
♦ Engine Bung Set - VAS6122-
♦ Coolant Collection System - VAS5014- or Shop Crane - Drip
Tray - VAS6208-
♦ Hose Clip Pliers - VAS6362-
♦ Torque Wrench Adapter - VAS6948-
♦ Locking Pin - T10060A-
♦ Engine Support - Supplement Kit - Adapter - T40093/6- from
the Engine Support - Supplement Kit - T40093B-
♦ Wrench - 21mm - T40263-
♦ Adapter - T40314-
♦ Protective Eyewear
♦ Safety Gloves
Procedure
• Remove the engine upward without the transmission.
• During installation, all cable ties must be installed at the same
location.
– Observe the guidelines for clean working conditions. Refer to
⇒ Servicing – 4-Cylinder 1.8L; 2.0L 4V TFSI Engine; Rep. Gr.
00 ; Repair Information; Guidelines for Clean Working Condi‐
tions .
Audi A4 2015 ➤ , Audi A4 China 2016 ➤ , Audi A5 2016 ➤
4-Cylinder Direct Injection 2.0L 4V TFSI Engine (EA 888 Generation III) - Edition 11.2019
4 Rep. Gr.10 - Engine Assembly
