CXiR Receiver
○○○ ○○○○○○○○○○○○○○○○○○○○○
Technical specification
Frequency range 470MHz–1000MHz
Number of frequencies 32 pre-programmed
Switching bandwidth 24MHz
Sensitivity -98dBm for 40dB SINAD
Frequency response 50Hz to 18kHz ±1dB
THD <0.2% typical
Signal to noise ratio 96dB to over 104dB
External power 7-18V DC
150-55mA
Antenna connector 2xSMA
Output connector 6 pin LEMO TM
Interchangeable module 15 pin D-type (Sony)
25 pin D-type (Ikegami)
44 pin D-type (Philips)
Size 98 x 60 x 18mm
Weight 150g
Operating range -20C˚ to +55˚C
Compliant to ETS 300 422 EN 300 445(CE)
FCC
