MXiR Receiver
○○○ ○○○○○○○○○○○○○○○○○○○○○
Technical specification
Frequency range 470MHz–1000MHz
Number of frequencies 32 pre-programmed
Switching bandwidth 24MHz
Sensitivity -98dBm for 40dB SINAD
Frequency response 50Hz to 18kHz ±1dB
THD <0.2% typical
Signal to noise ratio 96dB to over 104dB
External power 7-12V DC
Battery 9V PP3 IEC 6LR61 Alkaline
Antenna connector SMA
Output connector 6 pin LEMO TM
Size 110 x 60 x 18mm
Weight 170g
Operating Range -20˚C to +55˚C
Compliant to ETS 300 422 EN 300445(CE)
FCC
