Audio Ltd. Envoy - HXiR Hand-Held Transmitter

88
21
CHAPTER
5
HXiR Hand-Held
Transmitter
The HX iR is a multi-frequency UHF hand-held
transmitter for use with the RMS 2020 receivers, or
receivers from the Envoy Range. It is also
compatible with receivers from the RMS 2000 range.
It provides 32 switchable frequencies, and is
configured entirely by infra-red control using the
Switch
iR . The HX iR can be used with a range of
microphone capsules from the Schoeps Colette
series, and features a robust ergonomic design with
a microphone suspension designed to minimise
handling noise.
○○○ ○○○○○○○○○○○○○○○○○○○○○
Controls, displays, and connections
AA
+
Coloured ID
button
Microphone
capsule
Windshield
Transmitter
body
Coloured
identification
ring
Infra-red
port
On button
On/Overload
Indicator
Battery
compartment
with integral
antenna
