Audio Ltd. Envoy - Table of Contents

88
3
Contents
Introduction 5
Audio Limited ........................................................................ 5
The Envoy Range .................................................................. 5
Diversity reception ............................................................... 7
Selecting frequencies ......................................................... 8
Switch iR Infra-Red Controller 9
Using Switch iR ...................................................................... 9
CX iR Diversity Receiver 11
Controls, displays, and connections ............................... 11
Setting up the CX
iR ............................................................ 12
Technical specification ..................................................... 17
TX Blue Pocket Transmitter 18
Controls, displays, and connections ............................... 18
Setting up the TX Blue ....................................................... 19
Technical specification ..................................................... 20
HX iR Hand-Held Transmitter 21
Controls, displays, and connections ............................... 21
Setting up the HX
iR ............................................................ 23
Fitting the microphone capsule ....................................... 27
Holding the HX
iR ................................................................. 27
Technical specification ..................................................... 28
MX iR Receiver 29
Controls, displays, and connections ............................... 29
Setting up the MX
iR ........................................................... 30
External powering .............................................................. 33
Technical specification ..................................................... 34
Aud iR Infra-Red Controller 35
Installing Aud iR ................................................................... 35
Running Aud
iR .................................................................... 35
