CXiR Receiver
Connecting the antennae
Connect the antennae to the SMA connectors marked
RX1 and RX2. Connect the straight antenna to one
socket and the right-angled antenna to the other socket.
Selecting the operating frequency
You can check or change the operating frequency of the
CX
iR
receiver via infra-red control using the Switch
iR
.
To check the CX
iR
frequency:
• Press MENU.
The display shows:
FREQUENCY
MHz
Fr
• Align the front of the Switch
iR
with the infra-red
window on the receiver and press OK.
Optimum operating range is between 5 and 15cm.
The Switch
iR
will display the
receiver frequency; for example:
FREQUENCY
Rx MHz
854.900
To change the CX
iR
frequency:
• Press OK again.
The display will alternately flash between frequency and
channel number.
For example:
CHANNEL
01
• Press a or v to scroll through the 32 frequencies
read from the receiver until the required channel or
frequency is displayed.
For example:
CHANNEL
32
• Align the front of the Switch
iR
with the infra-red port
on the receiver and press OK.
If the command was received correctly the display will
show the new frequency.
For example:
FREQUENCY
Rx MHz
857.950
Otherwise the display will show:
Error
