MXiR Receiver
If the associated transmitter is on while the DC status is
being checked the display will alternate between the
receiver’s DC status and the received transmitter status.
For example:
Tx
H
The transmitter status is shown as one of the following
options:
Option Description
H (high) Indicates good.
L (low) Indicates low. Replace as soon
as possible.
F (failed) Transmitter will not function
correctly.
Indicators during correct operation
The red, no signal indicator will be lit if the
corresponding HX
iR
or TX Blue transmitter is not
switched on, or is set to the incorrect frequency.
○○○ ○○○○○○○○○○○○○○○○○○○○○
External powering
A number of different cables and accessories are
available from Audio Limited to allow the MX
iR
receiver
to be externally powered, and also to allow the receiver
to be interfaced with various devices.
