MXiR Receiver
To change the receiver output level:
• Press the OK button.
The AF level display will flash.
• Press the a or v button to step between the
available output level settings until the required
output level is displayed.
For example:
AF LEVEL
TxRx
-15 dB
• Align the front of the Switch iR with the infra-red port
on the receiver and press OK.
If the command was received correctly the new level
will be displayed.
For example:
AF LEVEL
TxRx
-15 dB
Otherwise the display will show:
Error
• Repeat the above steps if an error message is
displayed, with the Switch
iR closer to the receiver.
Headphone output level
The headphone output level operates in parallel with the
microphone output level. If the headphone monitoring is
utilised simultaneously with the microphone output
connected, then care should be taken not to adjust the
levels as the level control will effect both outputs.
The headphone output level is adjusted in the same
manner as the microphone output level with the
Switch
iR .
Checking the power status
To check the status of the receiver’s DC power:
• Press MENU.
• Press a three times until
the display shows:
TxRx
BAtt
• Align the front of the Switch iR with the infra-red port
on the receiver and press OK.
The display will
show the DC voltage:
Rx
9.0 v
