HXiR Hand-Held
Transmitter
Windshield
Can be unscrewed to access the microphone capsule.
Microphone capsule
Any capsule from the Schoeps Colette range can be
used with the HX
iR transmitter. There are 18 different
capsules available, ranging from a hyper-cardioid to an
omni pattern. Three capsules are also available from
Audio Limited.
Identification ring and button
The HX iR is supplied with six colour identifying rings and
buttons to aid recognition in multi-channel use. The ring
is indented to prevent the HX
iR from rolling when placed
on a flat surface, such as a table.
Infra-red port
Receives commands from and transmits status
information back to the Switch
iR infra-red controller.
On button
Switches the microphone on.
To prevent the microphone from accidentally being
switched off during use the HX
iR can only be switched
off by using the Switch
iR , or by briefly disconnecting the
battery.
On/overload indicator
The ring above the battery compartment glows red while
the HX
iR is switched on, but will flash off to indicate an
overload if the microphone experiences a loud signal.
Battery compartment
Holds one AA 1.5V (LR6 type) alkaline battery.
Antenna
The transmitter antenna is integrated into the battery
compartment and therefore no external antenna is
required.
