HXiR Hand-Held
Transmitter
• Align the front of the Switch iR with the infra-red port
on the HX
iR and press OK.
The display shows the current
frequency; for example:
FREQUENCY
Tx MHz
854.900
To change the frequency:
• Press OK.
The display will alternately flash between showing the
frequency and channel number.
For example:
CHANNEL
01
• Press a or v to scroll through the 32 frequencies
read from the transmitter until the desired frequency
or channel is displayed.
For example:
CHANNEL
32
• Point the Switch iR at the infra-red port on the HX iR
and press OK.
If the command was received successfully the display
will show the new set frequency.
For example:
FREQUENCY
Tx MHz
857.950
Otherwise it will show:
Error
• Repeat the above steps if an error message is
displayed, with the Switch
iR closer to the receiver.
Setting the gain
The steps between 0-9 gain settings are approximately 3
to 4dB. Set the gain position so that the overload
indicator does not flash off during normal operation.
To check the gain setting:
• Press MENU followed by a.
The display will indicate:
AF LEVEL
TxRx
AF
• Align the front of the Switch iR with the infra-red port
of the HX
iR and press OK.
HXiR Hand Held
Transmitter
