Index
88
46
HX
iR
hand-held transmitter (
continued
)
technical specification 28
M
MX
iR
receiver 6, 29
checking power status 32
controls, displays, and connections 29
external powering 33
fitting the battery 30
headphone output level 32
indicators 33
selecting the frequency 30
setting the output level 31
technical specification 34
R
RK 2 minirack, cable wiring diagrams 41
S
Switch
iR
infra-red controller 5, 9
menus 10
T
technical specifications
CX
iR
diversity receiver 17
HX
iR
hand-held transmitter 28
MX
iR
receiver 34
TX Blue 20
troubleshooting 39
TX Blue pocket transmitter 5, 18
connecting the antenna 20
connecting the audio input 20
controls, displays, and connections 18
external powering 19
fitting the battery 19
selecting the operating frequency 19
setting the microphone gain 20
technical specification 20
W
wiring diagrams 41
