12
➎ Indicator
LED that shows the status of the receiver.
When unmuted: Solid green
When muted: Solid red
➏ Display
Shows the current status. If no buttons are pressed for a period of 30 seconds, the display will turn off.
➐ SYNC button
Use to IR SYNC with the transmitter.
➑ UP button
Use to select various settings.
➒ BACK button
Press to take the display back one screen. Press and hold to return to the main screen.
➓ SET button
Press to display the settings screen. Select the setting item and press to confirm the selection.
⓫ DOWN button
Use to select various settings.
⓬ Battery cover
⓭ IR sync window
Use to IR SYNC with the transmitter
.
⓮ Charging terminal
Note
• When using the ATW-CHG3 or ATW-CHG3N Two-Bay Charging Station (sold separately), the receiver can
be charged.
