22
ATW-R3250
Main screen
➊ AF level indicator
Displays the level of the audio signal received by the receiver.
For AF peak, “!” mark will appear.
➋ Frequency display
Displays the specified frequency.
➌ Mute display
➍ Lock status display
➎ AF mode display
ST: Stereo
MX: Mix
MB: Mono/Balance
➏ Battery level display
The level indicator of the icon changes depending on the remaining battery level.
Four: At least 75% battery power remaining.
Three: 50-75% battery power remaining
Two: 25-50% battery power remaining.
One: Battery level is below 25%.
One (flashing): Battery power is low.
0: Replace/recharge batteries.
➐ Cue mode display
➑ RF mode display
ST: Stereo
MO: Mono
3KL: 3000Link
➒ RF level indicator
Displays the reception status.
