Audio Technica 3000 Series User Manual

68
Specifications
Overall system specifications
Operating frequencies
[1]
Band DF2: 470.125 to 607.875 MHz
Band EG2: 580.000 to 713.850 MHz
Minimum frequency step
25 kHz
Modulation mode
FM
Nominal/Peak deviation
±34 kHz nominal / ±45 kHz peak
Dynamic range
>90 dB, A-weighted, typical
Total harmonic distortion
<0.2% (at 1 kHz, +4 dBu input)
Operating range
[2]
90 m (300')
Frequency response
40 Hz to 14,100 Hz
Stereo separation
75 dB
Maximum simultaneous use
(recommended)
[3]
49 ch per band
[1] Please note that some frequency bands might not be available in your territory or could come with a limited tuning bandwidth / transmitting power due
to local regulations.
[2] Open range environment with no interfering signals.
[3] For assistance with multi-band operation or other frequency coordination issues, contact your local audio-technica dealer.
ATW-T3205
RF output power
[1]
High: 50 mW, Low: 10 mW (switchable) at 50 ohms
Input connection
XLR-F type×2
(Pin1: GND, Pin2: Hot, Pin3: Cold)
Maximum input level
XLR-F type: +24 dBu (at 0 dB sensitivity)
Output connection
6.3 mm (1/4”) TRS×2
(Tip: Hot, Ring: Cold, Sleeve: Ground）
Network
100BASE-T
Network port
RJ-45
Power supply
100 to 240 V AC (50/60 Hz) to 12V DC 1 A (center positive) switched mode
external power supply
Antenna output
BNC-type, 50 ohms
Dimensions
210 mm (8.3”)×191 mm (7.5”)×43.4 mm (1.7”) (W×D×H)
Weight (without accessories)
1,100 g (39 oz)
Included accessories
AC adapter
Rack-mount (large, small)
Flexible UHF antenna
[1] May differ depending on the country or region in which you live.
